CE Certified Tabletop Programmable High-Speed Small Spin Coater for Sale

  • 1 - 1 Sets
    $4,288.00
  • >=2 Sets
    $1,999.00
Model Number:
CY-Spin-100
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 15 Negotiable
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Type:
Coating Production Line
Substrate:
Copper
Coating:
Vacuum Coating
Place of Origin:
Henan, China
Brand Name:
CYKY
Voltage:
220V/110V, 220V / 110V
Power(W):
350W
Dimension(L*W*H):
450mm Depth *280mm W *340mm H
Weight:
46KG
Certification:
CE, CE Certificated
Warranty:
1 Year, 1 Year
After-sales Service Provided:
Online support
Usage:
spin coater
Application:
Substrate coating
Keyword:
spin coater price
Product name:
spin coater price
Coating Technology:
VACUUM SPIN COATER
Packing:
PLY WOODEN BOX
Technology:
Rotating centrifugation
Product Certification Verified
CE Certified.
Valid from 2015-04-01 until 2049-12-31
Supply Ability
Supply Ability:
899 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Plastic paper inside, polyfoam filled, plywood box outside
Port
zhengzhou,beijing,qingdao,etc
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 15 To be negotiated



Programmable Hi-Speed Spin Coater is CE certified tabletop spin coating device dedicated to spin coat small substrates up to 100 mm diameter at Max. 10000 rpm. The spin head actuator is a precision DC servo motor with accurate speed and acceleration control. The substrate can be held by vacuum (for thinner objects).The device has a user-friendly keyboard and LCD display for programming various parameters up to 12 programs, 6 segments. Spin duration, spin speed, and acceleration can be programmed from the front panel. All components in the device are corrosion protected to make it cleanroom compatible.

Main Feature:

1. Vacuum adsorption method to fix the sample, easy to operate

2. Use the positioning tool to easily place the sample in the center position to reduce the vibration caused by the eccentricity or the flying piece

3. According to the sample specifications, different suction cups can be used, and the replacement is convenient and simple.

4. There are 12 sets of procedures to ensure the consistency and uniformity of the coating thickness.

5. The degree of vacuum can reach -0.05MPa

6. Accept substrates from 5 mm to 5 inches

7. PP chamber is used for anti-corrosion operation.

8. An air inlet at the top of the cover that can be filled with inert gas during the coating process, including a 20 ml plastic syringe

9. Ar gas can be used (the vacuum pump must be outside the glove box)

10. Safety interlock is integrated in the cover







echnical Parameters:

Motor power

 350w

Speed range

Programmable speed of 500~10000 rpm

Program operation

12 sets of programs can be stored, each set contains 6 running stages

Increase and decrease rate setting range

100rpm/s-2000rpm/s

Time range

0-60s

Suction cup

Φ19mm, Φ60mm

This machine can be equipped with heating function

heating range RT-100°C

Input Power

AC 220V (Please email us for AC 110V Version)

1000 W total for oilless pump and spin cater

24VDC high speed motor



Shipping Weight

46 kg (100 lbs)

Shipping Dimensions

40"(L) x 30"(W) x 30"(H)

Warranty & Compliance



One year limited with lifetime support

Rusting and damage due to improper storage condition or maintenance are not covered by warranty

Product Dimensions

450mm Depth ×280mm W ×340mm H

Installation Conditions:

This equipment is required to be used at an altitude of 1000m or less, a temperature of 25°C±15°C, and a temperature of 55% Rh±10%Rh.

Water

Equipment is equipped with inlet and outlet

Electricity

AC220V 50Hz, must have good grounding

Gas

no need

Workbench

size 600mm*600mm*700mm, bearing weight 50kgs or more

Ventilation

need





Founded in 2005, Zhengzhou CY Scientific Instrument Co., Ltd. is a company specializing in the development and production of laboratory technology research equipment. The products are mixed, pressed, burned, cut, ground, polished, coated, analytical equipment and related consumables. Products include laboratory sintering equipment, coating equipment and so on. At present, it has been exported to 25 countries and regions such as the United States, Europe, and Southeast Asia, and has been well received by various scientific research units.



We have a mature technology research and development team, the number of technicians is 33, the company has 150 people, more than 500 square meters of office space, the factory covers an area of about 1,500 square meters located in Zhengzhou High-tech Zone Electronic Industrial Park. The products are mainly located in the research market, serving scientific research in the labs of universities and colleges, and can also customize products according to your needs.
